Simpleware for Complex Materials Modeling
3D image processing and meshing software
Simpleware software is used for 3D image data (CT, micro-CT, FIB-SEM...) segmentation, 3D image processing and model generation for complex materials analysis. Characterize composite microstructures and use powerful meshing software tools to export models to FE and CFD solvers. Rapidly obtain qualitative and quantitative information from your 3D image data, including effective material properties.
Measure Image Data and Obtain Statistics
- Measure distances, angles (fracture dimensions...)
- Compute statistics for regions of interest and models (volume, surface area, average greyscale, material properties, porosity...)
- Use centerline statistics
- Create user-defined statistics
Generate Meshes for FE and CFD
Segmented image data can be exported as simulation-ready multi-domain meshes using FE and CFD meshing software tools, ready to use in all leading solvers.
- Meshes feature conforming interfaces and shared nodes
- Define FE contact pairs, node sets and shells
- Define CFD boundary conditions
- Assign material properties
- Optimize mesh quality to specific metrics
Calculate Effective Material Properties
The modules Simpleware SOLID (elastostatic properties), Simpleware FLOW (absolute permeability) and Simpleware LAPLACE (electrical conductivity/thermal conductivity, molecular diffusivity), enable calculation of effective material properties. Quantify scanned composite samples with an easy-to-use software workflow.
- Use full FE-based simulations with built-in solver or quick calculation of analytical bounds (SOLID, LAPLACE)
- Reduce effects of boundary conditions
- Visualize fields obtained from FE simulations
- Export results as text and image files
Use Scripting to Automate Workflows
The software's functionality can be accessed using an integrated scripting interface, and through languages such as Python, Iron Python, C#, Java, Visual Basic and Boo. Macro recording and a log history converter can also be used to automate steps, while user-created plug-ins can be incorporated within the software to improve efficiency when processing image data.
Case Studies
Contact Information
If you are interested in Simpleware software or need additional information, please contact us.
