Verification IP for Ethernet Base-T

Specifications

• IEEE 802.3 Clause 24 (100 Base-X), Clause 28 (Auto-Negotiation on twisted pair), Clause 40 (1000BASE-T), Clause 96 (100BASET1), Clause 97 (1000BASET1), Clause 98 (Single twisted-pair Auto-Negotiation), Clause 125,126 (2.5/5G BASE-T), cg Clause 147 (10BASE-T1S), Clause 148 (PLCA)
• OPEN Alliance 10BASE-T1S Transceiver

DUT Types/Topology: MAC to MAC, MAC+PHY(serial/parallel) to MAC+PCS (serial/parallel)

Key VIP Features

• Flexibility to enable / disable Scrambler
• VIP to be programmed in Master/Slave mode
• Flexibility to enable / disable initial noise insertion

Debug and Analysis

• Verdi based protocol and performance analysis
• Protocol checks at each layer
• Debug ports and trace files
• View all Ethernet Frames at the MAC Layer
• Browse multiple transactions in sync with wave and log views
• Extensive filtering to speed debug

Key Protocol Features

• Flexibility to enable / disable Scrambler
• Programmable RS FEC Error Correction, Scrambler Seed value
• Programmable match/mismatch count for  assertion/ de-assertion of scr_status, loc_rcvr_status, rem_rcvr_status etc
• Feature set for 10BaseT1S
• User programmable 10BaseT1S Timers.
• Variable jitter support
• User programmable Base T1 Timers [For example: LPI / Stabilize / AN /Link Sync etc timers]
• Programmable Info Field register values

Test Suites / Groups Features

• Transition of Link Sync /TX /RX State Machine
• Info Field encoding and decoding
• 80b/81b , 4b/3b Encoding /Decoding, RS- Decoder
• 3b2T Data manipulation
• EEE / OAM Verifying tests
• Test Pattern Modes
